G5

G5 is a multi-biometric access control terminal designed for outdoor use, the product supports various biometric authentication, including facial recognition, fingerprint verification, multi-tech cards detection and password. It also features an 8-inch TFT color touch screen with slim bezel design and IP66 waterproof & dustproof and IK04 vandal-proof protection level.

Parameters

Model

G5
Operating System

Android 9.0
CPU

64bit Eight Core Customized Computer Vision CPU
SDK

Android LCDP, PUSH SDK
Communication

TCP / IP, Wi-Fi, Bluetooth, USB
Display

8 inch TFT LCD Color Screen
Screen Type

Capacitive Touch Screen
Resolution

800*1280
Camera

2MP Binocular Camera
QR Code

Optional: Dynamic QR codes on the ZKBio CVSecurity mobile application QR code, PDF417, Data Matrix, MicroPDF417, Aztec scanning in third-party development projects
Card Type

Dual-frequency (125kHz and 13.56MHz)
card module (standard)
Multi-tech Card Module (optional)
ISO14443A / B & ISO15693 & HID Prox
Access Control Interface

USB: 1 USB 3.0, 1 USB 2.0, 1 Micro USB;
Power Adapter: 12V 3A;
Ethernet: RJ45, 1000M;
RS232: 1;
RS485: 1;
Wiegand: 1 input, 1 output;
Auxiliary input: 1;
Sensor: 1;
Exit Button: 1;
Lock: 1;
Alarm: 1;
Bell: 1
Power out: 1, 12V
Reset Button: 1
Ingress Protection Rating

IP66 without Fingerprint / QR Code Reader
IP65 with Fingerprint / QR Code Reader
IK04
Touchless Biometric Recognition Distance

Card: 1cm–5cm
Face: 0.3 m to 1.2 m & Human height: 0.9 m to 2.4 m
Biometric Verification Speed

Face(1:1, 1:N): < 1s
Fingerprint(1:1, 1:N): ≤0.5s
Biometric Algorithm

Face: ZKFace 5.6.2 & Fingerprint: ZKFinger 10.0
False Acceptance Rate (FAR) %

Face: 0.01%
False Rejection Rate (FRR) %

1%
User Capacity

100,000
Face Capacity

100,000
Fingerprint Capacity

30,000 (Optional)
Card Capacity

100,000
Transaction Capacity

5,000,000
Standard Function

Push, Schedule Bell, Automatic Status Switch, Record Query, Access Levels, Groups, Holidays, DST, Duress Mode (Password & Fingerprint), Anti-Passback, Customization of Wallpaper & Screen Saver,Tamper Alarm
Supported Software

ZKBio Time, ZKBio CVSecurity
Power Supply

12V 3A; PoE (IEEE802.3af / at)
Dimensions

279.5mm*141mm*29mm(11in*5.55in*1.14in)
Operating Temperature

-10℃ to 50℃ (14°F to 122°F)
Operating Humidity

<90%RH
Gross Weight

1.2kg
Installation

Wall-mounted or Turnstile top-mount bracket
Certifications

CE, FCC, ISO9001, ISO14001, IP66, IK04
