Parameters

• Model

  ZK-IWB65BE; ZK-IWB75BE; ZK-IWB86BE

• Size

  ZK-IWB65BE: 65-inch
  ZK-IWB65BE: 75-inch
  ZK-IWB65BE: 86-inch

• Screen Type

  D-LED (Backlight)

• Display Parameters

  Resolution: 3840 × 2160 (pixels)
  Brightness: 400cd/m² (typ.)
  Contrast Ratio:1200:1 (typ.)
  Response Time:ZK-IWB65BE: 6ms (typ.); ZK-IWB75BE: 8ms (typ.); ZK-IWB86BE: 8ms (typ.)
  Frequency: 60Hz
  Aspect Ratio: 16:9
  View Angle: 178°(H) / 178°(V)
  Display Colors: 1.07B(8bit+FRC)
  Bonding Technology: The gap between tempered glass and screen is close to 0

• Power Parameters

  Power Consumption (Without OPS):
  ZK-IWB65BE: 220W
  ZK-IWB75BE: 300W
  ZK-IWB86BE: 380W
  Working Voltage: AC 176V to 264V, 50/60Hz
  Power Type: AC Power
  Standby Consumption: <0.5W

• Touch Parameters

  Touch Technology: Advanced infrared touch technology
  Anti-Glare: High transparent + Smooth + Anti-glare
  Tempered Glass: Toughened Glass 3.2mm
  Grade: MoHS 7
  Touch Points: Android: 20 Multi-touch points: Windows: 40 Multi-touch points
  Input: Stylus / Finger / Other solid(soft tip) object
  Accuracy: ±1mm (middle 0ver 90% area)
  Writing Height: 3.0 mm
  Resolution: 32768×32768
  Response Time: <5ms
  Minimum Touch Object: Single touch: ≥1.6mm
  Multiple touch: ≥2.0mm
  Support Pen Protocol: Windows Whiteboard 2.0 support thick and thin pens Automatic identification
  Recognition Level Of Thick And Thin Pens: 4 Grades :3mm / 8mm / 12mm fine eraser / 25mm eraser

• Connectivity

  Front Port: USB 3.0*2, Type-C*1, Touch-USB*1, HDMI2.0*1
  Bottom Port: LAN IN/OUT*2, RS232 IN*1, MIC IN*1, AUDIO OUT*1, SPDIF OUT*1
  Side Port: Touch-USB*2, HDMI IN*2, USB 2.0*1, USB 3.0*1

• Mainboard

  Solution: T982
  CPU: Architecture: Quad core ARM Cortex A55
  Operating frequency < 1.8GHz
  OS: Android 13.0
  GPU: MaliG52 2EE MC1@550MHz
  RAM: 4GB
  ROM: 32GB
  OPS (Optional): Windows11.0

• WiFi

  Main Chipset: Wi-Fi+BT MT7663BU (IEEE 802.11a/b/g/n/ac) Bluetooth v5.1 2T2R 2.4GHz / 5GHz
  Operating Frequency: 2.4GHz / 5GHz
  Wi-Fi Standard: IEEE 802.11 ax / b / g / n / ac
  Bluetooth: 2.1+EDR / 4.2 / 5.1

• Speaker

  Output Power: 8Ω /16W×2: 200Hz - 20kHz

• Physical Parameters

  Product Dimensions (L*W*H):
  ZK-IWB65BE: 1482.1×87.7×897.4 (mm)
  ZK-IWB75BE: 1716.5×87.7×1031.8 (mm)
  ZK-IWB86BE: 1967.8 x87.7.x1169.9 (mm)
  Package Dimensions (L*W*H):
  ZK-IWB65BE: 1640×185×1010 (mm)
  ZK-IWB75BE: 1860×185×1125 (mm)
  ZK-IWB86BE: 2095×185×1265 (mm)

  Net Weight

  ZK-IWB65BE: 38±1.5 kg
  ZK-IWB75BE: 52.5±1.5kg
  ZK-IWB86BE: 65.5±1.5kg
  Weight with Packaging:
  ZK-IWB65BE: 46±1.5 kg
  ZK-IWB75BE: 61.5±1.5kg
  ZK-IWB86BE: 77±1.5kg
  Case Material: Aluminium Alloy and Sheet Metal
  Color: Black

• General Environment

  Operating Temperature: 0°C to 40°C
  Storage Temperature: 10°C to 60°C
  Operating Humidity: 20% to 80% RH (Non-condensing)
  Storage Humidity: 10% to 60% RH (Non-condensing)
